TECHNICAL SPECIFICATIONS
| Sr. No. | CHARACTERISTIC | EURO Standard EN-159/IS13759 |
Parisian Standard Value EN-159/IS13759 |
|---|---|---|---|
| Dimension & Surface Quality | |||
| 1 | Dimension & Surface Quality | 0.5% | 0.4% |
| 2 | Deviation in thickness | 0.6% | 0.5% |
| 3 | Straightness of sides | 0.3% | 0.2% |
| 4 | Rectangularity | 0.5% | 0.3% |
| 5 | Surface flatness | 0.5% | 0.3% |
| 6 | Surface Quality | Min. 95% | Min. 96% |
| Physical Properties | |||
| 1 | Water Absorption | >0.10% | 15-16% |
| 2 | Bending Strength | >150 kg./Cm² | >150-180 kg./Cm² |
| 3 | Scratch Hardness (mohs scale) | Min. 3 | Min. 3 |
| 4 | Crazing Resistance | 1 Cycle | No Crazing upto 3 Cycle |
| 5 | MOR Value | 12-14 N/mm² | 16 N/mm² |
| Chemical Properties | |||
| 1 | Staining Resistance | Min. Class 2 | Resistant to all Acids and Alkalies & Household Chemicals, except Hydro Flouric Acid. |
| 2 | Impact Resistance | Min. Class B | |
| Thermo Hydrometric Properties | |||
| 1 | Thermal Shock Resistance | Resistant 10 Cycle | Conforms |
| 2 | Thermal Expansion | Max. 9E-06 | Conforms |
| Nominal Size | Thickness | No. of tiles / box | Coverage Area / Box | Weight / Box |
|---|---|---|---|---|
| 300x300mm | 9.5mm | 8 Pcs | 0.72 Sq. Mtr. | 11.5 kg |
